3100Hz Φ96.7*3.7mm Magnetic Passive Buzzer
3100Hz Φ96.7*3.7mm Magnetic Passive Buzzer 3100Hz Φ96.7*3.7mm Magnetic Passive Buzzer

3100Hz Φ96.7*3.7mm Magnetic Passive Buzzer

Product ID : LET6737F
Product Tags :
Product Description

Application:

Automotive alarms;

Toys, games machines etc;

Electrical appliances;

Automatic control devices;

Conveyors, medical equipment;

Fire alarms, burglar alarms, gas detectors;

Data processing equipment etc



Specifications:

Rated Voltage (Vo-p):               3

Max input Voltage (Vo-p) :       4

Rated Current (mA) :                80 max.

Coil Resistance:                        16±3 ohms

Sound Output @10cm(dB):      75 min.

Resonant Frequency (KHz):       3.1

Operating Temperature (℃):    -20~ +60

Storage Temperature(℃):         -30~+80



For more details, please contact us.
